Manufacturer: Ricoh

Technical Specifications

- Size: 13,2 x 120 x 75,5 mm (excluding cables)

- Head Materials: SST, Ni and Epoxy Adhesive (direct contact with ink)

- Nozzle Plate Surface: Non-wet coating

- Number of Nozzles: 2 x 192 nozzles

- Nozzle Spacing: 0,1693 mm

- Piezo Type: D33 Stacked PZT

- Temperature Control: Integrated Heater and Thermistor

- Operator Temperature range: Up to 80° C

- Native Drop Volume: 27 pl

- Drop Volume Range: 27-54 pl

- Jetting Frequency: Up to 30 kHZ

- Life: 100 billion actuations per nozzle
