STARFIRE SG1024/MA PRINTHEAD

The StarFire SG1024/MA is a compact, self-contained unit built to withstand demanding industrial textile and other applications. It uses field-proven materials to deliver consistent output over a long service life with continuous ink recirculation and single-color operation at 400 dots per inch from 1024 independent channels arranged in eight rows in a single replaceable metal nozzle plate that is designed to withstand abrasion. The unit is compatible with solvent, UV curable and aqueous ink formulations.

Each SG1024/MA printhead has 1024 independent channels arranged in 8 rows in a single nozzle plate for resolutions up to 400 dpi. All 1024 nozzles can be fired simultaneously or individually.

Features:

. Robust and repairable construction

. 30 picoliter nominal drop size

. 1024 individually addressable jets

. Incorporate VersaDrop™ binary and grayscale jetting

. Continuous ink recirculation with RediJet™

. Removable/replaceable coated metal nozzle plate
