Epson delivers a first-of-its-kind design that redefines speed, versatility and efficiency for its class: the SureColor® T7770DL. Having the smallest footprint in its class1—up to 25% smaller than its competition1—and full-front operation means the T7770DL fits where other printers don’t. It’s designed for outstanding quality, sharpness and speed, generating technical drawings at production-class speeds over 1,400 ft2/hr2, A1/D-size prints in as little as 16 seconds2, and graphics at speeds up to 300 ft2/hr2. Its innovative UltraChrome® XD3 six-ink set with dedicated Red Ink opens the door to both an extraordinary color gamut for a production printer and rich red branding colors. Built with a 1.6-liter bulk ink pack system (ink sold separately), this high-quality printer provides over double the ink capacity of previous generations for a remarkably low ink cost per milliliter, as well as helps minimize waste when compared to Epson® SureColor T-Series cartridge systems. And simple, carefree operation combined with new levels of versatility and media flexibility helps users do more using less space—all with a low total cost of ownership. Add it all up, and this is not just a one-of-a-kind printer: it’s the new benchmark in high-speed CAD and graphics.
SPECIFICATION :
| Printing Technology | PrecisionCore MicroTFP 6-channel, drop-on-demand |
| Ink Type | UltraChrome XD3 pigment ink; 6-color with Red (Cyan, Magenta, Yellow, Red, Matte Black, Photo Black) |
| Nozzle Configuration | 9,600 nozzles (1,600 x 6 channels) |
| Droplet Technology | Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to 3 different sizes per nozzle |
| Maximum Resolution | 2400 x 1200 dpi |
| Real-Time Black Ink Selection | Dedicated Photo and Matte Black Ink channels selected automatically based on media type |
| Print Speed | CAD (B0 Size Plain Paper): Over 1,400 ft2 /hr A1/D Size (Plain Paper): 16 sec Poster (Glossy): Over 300 sq ft 2 /hr |
| Printer Language/Drivers | Epson Professional Print Drivers (Included), Epson ESC/P® raster, HP-GL/2, HP RTL, Adobe ® PostScript® 3™ , Adobe PDF 1.7, Adobe Embedded Print Engine (Included) |
| Memory (Built-In) | 4 GB |
| Retail Ink Pack Fill Volume | Colors (C, M, Y, R): 1.6 L Black (MK, PK): 1.6 L |
| Number of Input Rolls | 2 (Input Roll #1 can be used optionally as a take-up reel) |
| Take-Up Reel | Included |
| Take-Up Reel Configuration | Roll print-side in or print-side out (selectable) |
| Minimum Roll Width | Minimum 10" |
| Maximum Roll Width | Up to 44" |
| 2" or 3" Core Diameter | User-adjustable roll media spindles |
| Roll Cutting | High-speed internal rotary cutter; auto or manual (replaceable) |
| Maximum Roll Diameter | Up to 6.69" |
| Maximum Roll Weight | 27 lb |
| Roll Media Thickness | 0.07 mm to 0.8 mm |
| Roll Paper Remaining | Printable barcode tracking The amount of remaining paper can be controlled and monitored automatically from the control panel. |
| Single Sheet, Front or Rear Loading | Up to 44" wide |
| Minimum Sheet Width | 8" |
| Minimum Sheet Length | 8" |
| Sheet Media Max. Thickness | up to 1.5mm (Rigid Posterboard) |
| Line Accuracy | ±0.1% or ±0.26 mm (whichever is greater) |
| Margin | Left/Right: 3 mm per side (standard) or 0 mm at BorderFree® widths |
| Top/Bottom | Roll Paper: Minimum: 3 mm top/bottom Cut Sheet: Min. 3 mm top and 12.7 mm bottom |
| BorderFree Sizes | 10", 13", 16", 17", 20", 24", 36" or 44" wide |
| Articulating LCD Display | 4.3" Touchscreen |
| USB Expansion Port | Optional RFID Card Reader |
| Printer Interfaces | SuperSpeed USB 3.0, 100BASE-TX /1000BASE-T/IEEE802.11b/ g/n/ac, USB memory stick*, 960 GB (SSD) Optional |
| Maximum Printable Length | 298 ft |
| Minimum Line Width | 0.08 mm |
| Operating Systems | Mac® OS X® 10.9.5 or later, macOS® 11 or later Windows ® 10, Windows 8.1, Windows 8, Windows 7, Windows Vista® , Windows XP (32-bit/64-bit), Windows Server® 2019/2016/2012, R2/2012/2008, R2/2008/2003, R2/2003 SP2 or later |
| Temperature | Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C) Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C) |
| Relative Humidity | Operating: 20%–80% (no condensation) Storage: 5%–85% (no condensation) |
| Acoustic Noise Level | Operating: 49.6 dBA Sleep: 6.6 dBA |
| Safety Standards | USA and Canada (NRTL Certified, CSA/UL 62368-1). Compliant with FCC Class B Requirements. |
| Power Consumption | Printing: Approx. 75 W Ready: Approx. 32 W Sleep: 2 W Power Off (Standby): 0.3 W |
| Electrical Requirements | Voltage: AC 110–240 V Frequency: 50–60 Hz Current: 3.4 A |
| Dimensions (W x D x H) | 73" x 19.6" x 38.4" (Storage and Operating) |
| Dimensions (W x D x H) | 73" x 32.6" x 38.4" (Paper Basket Extended) |
| Weight | 364 lb |
Epson SureColor T7770DL 44" Large-Format Dual-Roll CAD/Technical Printer
- Product Code: EP54443
Epson delivers a first-of-its-kind design that redefines speed, versatility and efficiency for its class: the SureColor® T7770DL. Having the smallest footprint in its class1—up to 25% smaller than its competition1—and full-front operation means the T7770DL fits where other printers don’t. It’s designed for outstanding quality, sharpness and speed, generating technical drawings at production-class speeds over 1,400 ft2/hr2, A1/D-size prints in as little as 16 seconds2, and graphics at speeds up to 300 ft2/hr2. Its innovative UltraChrome® XD3 six-ink set with dedicated Red Ink opens the door to both an extraordinary color gamut for a production printer and rich red branding colors. Built with a 1.6-liter bulk ink pack system (ink sold separately), this high-quality printer provides over double the ink capacity of previous generations for a remarkably low ink cost per milliliter, as well as helps minimize waste when compared to Epson® SureColor T-Series cartridge systems. And simple, carefree operation combined with new levels of versatility and media flexibility helps users do more using less space—all with a low total cost of ownership. Add it all up, and this is not just a one-of-a-kind printer: it’s the new benchmark in high-speed CAD and graphics.
SPECIFICATION :
| Printing Technology | PrecisionCore MicroTFP 6-channel, drop-on-demand |
| Ink Type | UltraChrome XD3 pigment ink; 6-color with Red (Cyan, Magenta, Yellow, Red, Matte Black, Photo Black) |
| Nozzle Configuration | 9,600 nozzles (1,600 x 6 channels) |
| Droplet Technology | Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to 3 different sizes per nozzle |
| Maximum Resolution | 2400 x 1200 dpi |
| Real-Time Black Ink Selection | Dedicated Photo and Matte Black Ink channels selected automatically based on media type |
| Print Speed | CAD (B0 Size Plain Paper): Over 1,400 ft2 /hr A1/D Size (Plain Paper): 16 sec Poster (Glossy): Over 300 sq ft 2 /hr |
| Printer Language/Drivers | Epson Professional Print Drivers (Included), Epson ESC/P® raster, HP-GL/2, HP RTL, Adobe ® PostScript® 3™ , Adobe PDF 1.7, Adobe Embedded Print Engine (Included) |
| Memory (Built-In) | 4 GB |
| Retail Ink Pack Fill Volume | Colors (C, M, Y, R): 1.6 L Black (MK, PK): 1.6 L |
| Number of Input Rolls | 2 (Input Roll #1 can be used optionally as a take-up reel) |
| Take-Up Reel | Included |
| Take-Up Reel Configuration | Roll print-side in or print-side out (selectable) |
| Minimum Roll Width | Minimum 10" |
| Maximum Roll Width | Up to 44" |
| 2" or 3" Core Diameter | User-adjustable roll media spindles |
| Roll Cutting | High-speed internal rotary cutter; auto or manual (replaceable) |
| Maximum Roll Diameter | Up to 6.69" |
| Maximum Roll Weight | 27 lb |
| Roll Media Thickness | 0.07 mm to 0.8 mm |
| Roll Paper Remaining | Printable barcode tracking The amount of remaining paper can be controlled and monitored automatically from the control panel. |
| Single Sheet, Front or Rear Loading | Up to 44" wide |
| Minimum Sheet Width | 8" |
| Minimum Sheet Length | 8" |
| Sheet Media Max. Thickness | up to 1.5mm (Rigid Posterboard) |
| Line Accuracy | ±0.1% or ±0.26 mm (whichever is greater) |
| Margin | Left/Right: 3 mm per side (standard) or 0 mm at BorderFree® widths |
| Top/Bottom | Roll Paper: Minimum: 3 mm top/bottom Cut Sheet: Min. 3 mm top and 12.7 mm bottom |
| BorderFree Sizes | 10", 13", 16", 17", 20", 24", 36" or 44" wide |
| Articulating LCD Display | 4.3" Touchscreen |
| USB Expansion Port | Optional RFID Card Reader |
| Printer Interfaces | SuperSpeed USB 3.0, 100BASE-TX /1000BASE-T/IEEE802.11b/ g/n/ac, USB memory stick*, 960 GB (SSD) Optional |
| Maximum Printable Length | 298 ft |
| Minimum Line Width | 0.08 mm |
| Operating Systems | Mac® OS X® 10.9.5 or later, macOS® 11 or later Windows ® 10, Windows 8.1, Windows 8, Windows 7, Windows Vista® , Windows XP (32-bit/64-bit), Windows Server® 2019/2016/2012, R2/2012/2008, R2/2008/2003, R2/2003 SP2 or later |
| Temperature | Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C) Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C) |
| Relative Humidity | Operating: 20%–80% (no condensation) Storage: 5%–85% (no condensation) |
| Acoustic Noise Level | Operating: 49.6 dBA Sleep: 6.6 dBA |
| Safety Standards | USA and Canada (NRTL Certified, CSA/UL 62368-1). Compliant with FCC Class B Requirements. |
| Power Consumption | Printing: Approx. 75 W Ready: Approx. 32 W Sleep: 2 W Power Off (Standby): 0.3 W |
| Electrical Requirements | Voltage: AC 110–240 V Frequency: 50–60 Hz Current: 3.4 A |
| Dimensions (W x D x H) | 73" x 19.6" x 38.4" (Storage and Operating) |
| Dimensions (W x D x H) | 73" x 32.6" x 38.4" (Paper Basket Extended) |
| Weight | 364 lb |
- Brand: Epson
- Availability: In Stock
USD 4,600.00
