Imagine a wide-format production photo printer engineered to achieve unbelievable quality and speed with innovative, automatic dual roll switching.
We’ve rethought photographic production printing from the ground up to deliver a high-performance solution built to enhance the way you work. Introducing the SureColor® P8570D — a new evolution in photographic production printing, only from Epson.
Featuring a completely reimagined printer design, with new automatic dual-roll capability, the SureColor P8570D seamlessly integrates into roll-to-roll workflows to produce stunning prints at true production speeds. The latest from a leader in image quality, the SureColor P8570D uses 6-color UltraChrome® PRO6 Ink with Gray to produce vivid, beautiful outputs that rival comparable 8-color printers. An innovative Adobe® Embedded Print Engine with four on-board Intel® Atom CPUs quickly processes complicated PDF data and accurately reproduces transparent design layers at speeds up to three times faster than previous generations. Designed to meet your production needs, this convenient printer offers customizable features and easy front-panel feeding and operation to deliver next-level productivity for your business.
SPECIFICATION :
| Printing Technology | PrecisionCore MicroTFP 6-channel drop on-demand printhead |
| Ink Type | UltraChrome PRO6 pigment ink; 6-ink, 6-color ink configuration: Cyan, Magenta, Yellow, Matte Black, Photo Black and Gray |
| Nozzle Configuration | 9600 nozzles (400 nozzles x 24 channels) |
| Droplet Technology | Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to 3 different sizes per line |
| Maximum Resolution | 2400 x 1200 dpi |
| Production Print Speed | Plain Paper: Draft (1P) 1657 sqft / hr Matte Paper: Speed (2P) 589 sqft / hr Photo Paper: Speed (4P) 381 sqft / hr Photo Paper: Quality (6P) 206 sqft / hr Photo Paper: Max Quality 94 sqft / hr |
| Printer Language/Drivers | ESC/P Raster, Adobe PostScript 3, Adobe PDF 1.7 |
| Memory/Built In | 4 Gig |
| In-Box Cartridge Fill Volume | 240 mL each color x 6 colors total |
| Retail Cartridge Fill Volume | 150 mL, 350 mL or 700 mL each color available x 6 colors total |
| Ink Cartridge Shelf Life | 2 years from printed production date or 6 months after opened Printer is designed for use with Epson cartridges only, not third- party cartridges or ink*. |
| Dual Front-Loading Rolls | Two 10" to 24" wide |
| 2" or 3" Core Diameter | User-adjustable roll media spindles |
| Roll Cutting | High-speed internal rotary cutter; auto or manual |
| Minimum Auto Cut Length | 5.0" plus top and bottom margin (5.24" min) |
| Maximum Roll Diameter | Up to 6.69" |
| Maximum Roll Weight | 27 lbs |
| Media Thickness | 0.07 mm to 0.80 mm (roll and sheet media) |
| Roll Paper Remaining | Printable barcode tracking system – The amount of remaining media can be controlled and monitored from the front panel |
| Top/Bottom Margins (mm) | Normal: 20/15 (Premium Luster Photo Paper); Option: Top 3, 15, 20, 45/Bottom 3, 15 |
| Left/Right Margins | 3 mm each side; 0.24" total; or 0" at BorderFree® width |
| Integrated Take-Up Reel | Auto forward and backward; light- based media sensor with inner and outer winding options |
| BorderFree Print Widths | 10", 11.8", 13", 16", 17", 20", 20.3", 23.4", 24", 28.7", 33.1", 36", 40.6", 44" |
| Single Sheet, Front or Rear Loading | up to 44" wide |
| Minimum Sheet Width | 8" |
| Maximum Sheet Width | 44" |
| Media Thickness | 0.07 mm to 0.8 mm |
| Posterboard | 0.8 mm to 1.5 mm |
| Top/Bottom Margins | 3 mm/15 mm |
| Top/Bottom Margins with Centering On | 15 mm/15 mm |
| Left/Right Margins | 3 mm each side; 6 mm or 0.24" total; or 0" at BorderFree sizes |
| Line Accuracy | ±0.1% of specified length (±0.26 mm min.) |
| Minimum Sheet Size (Single Sheet) | 8.5" x 11" |
| Maximum Printable Length | 298' |
| Minimum Paper Width | Roll: 10"/Sheet: 8" |
| Articulating LCD Display | 4.3" Touchscreen |
| Printer Interfaces | SuperSpeed USB 3.0, 100BASE-TX /1000BASE-T/IEEE 802.11 b/g/n/ac, USB memory stick, 960 GB SSD Optional |
| Operating Systems | Mac® OS X® 10.9.5 or later, macOS® 11 or later Windows® 10, Windows 8.1, Windows 8, Windows 7, Windows Vista® , Windows XP® (32-bit/64-bit), Windows Server® 2019/2016/2012 R2/2012/2008 R2/2008/2003 R2/2003 SP2 or later |
| Dimensions (W x D x H) | 73" X 20" X 39" |
| Weight | 347.2 lbs |
| Acoustic Noise Level | Operating: 49.6 dB(A) according to ISO 7779 |
| Temperature | Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C) Operating (Recommended): 65 ˚ to 75 ˚F (18 ˚ to 24 ˚C) Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C) |
| Relative Humidity | Operating: 20% – 80% (no condensation) Operating (Recommended): 45% – 60% (no condensation) Storage: 5% – 85% (no condensation) |
| Safety Standards | USA and Canada (NRTL Certified, CSA/UL 62368-1). Compliant with FCC Class B Requirements. |
| Electrical Requirements | Voltage: AC 110 V – 240 V Frequency: 50 Hz – 60 Hz Current: 3.4 A – 1.6 A |
| Power Consumption | Printing: Approx. 70 W Ready: Approx. 32 W Sleep: 2 W (1000Base-T Ethernet in Standby) Power Off (Stand By): 0.3 W |
Epson SureColor P8570D 44" Wide-Format Dual Roll Printer
- Product Code: EP54418
Imagine a wide-format production photo printer engineered to achieve unbelievable quality and speed with innovative, automatic dual roll switching.
We’ve rethought photographic production printing from the ground up to deliver a high-performance solution built to enhance the way you work. Introducing the SureColor® P8570D — a new evolution in photographic production printing, only from Epson.
Featuring a completely reimagined printer design, with new automatic dual-roll capability, the SureColor P8570D seamlessly integrates into roll-to-roll workflows to produce stunning prints at true production speeds. The latest from a leader in image quality, the SureColor P8570D uses 6-color UltraChrome® PRO6 Ink with Gray to produce vivid, beautiful outputs that rival comparable 8-color printers. An innovative Adobe® Embedded Print Engine with four on-board Intel® Atom CPUs quickly processes complicated PDF data and accurately reproduces transparent design layers at speeds up to three times faster than previous generations. Designed to meet your production needs, this convenient printer offers customizable features and easy front-panel feeding and operation to deliver next-level productivity for your business.
SPECIFICATION :
| Printing Technology | PrecisionCore MicroTFP 6-channel drop on-demand printhead |
| Ink Type | UltraChrome PRO6 pigment ink; 6-ink, 6-color ink configuration: Cyan, Magenta, Yellow, Matte Black, Photo Black and Gray |
| Nozzle Configuration | 9600 nozzles (400 nozzles x 24 channels) |
| Droplet Technology | Smallest Droplet Size: 3.5 picoliters; Variable Droplet Technology can produce up to 3 different sizes per line |
| Maximum Resolution | 2400 x 1200 dpi |
| Production Print Speed | Plain Paper: Draft (1P) 1657 sqft / hr Matte Paper: Speed (2P) 589 sqft / hr Photo Paper: Speed (4P) 381 sqft / hr Photo Paper: Quality (6P) 206 sqft / hr Photo Paper: Max Quality 94 sqft / hr |
| Printer Language/Drivers | ESC/P Raster, Adobe PostScript 3, Adobe PDF 1.7 |
| Memory/Built In | 4 Gig |
| In-Box Cartridge Fill Volume | 240 mL each color x 6 colors total |
| Retail Cartridge Fill Volume | 150 mL, 350 mL or 700 mL each color available x 6 colors total |
| Ink Cartridge Shelf Life | 2 years from printed production date or 6 months after opened Printer is designed for use with Epson cartridges only, not third- party cartridges or ink*. |
| Dual Front-Loading Rolls | Two 10" to 24" wide |
| 2" or 3" Core Diameter | User-adjustable roll media spindles |
| Roll Cutting | High-speed internal rotary cutter; auto or manual |
| Minimum Auto Cut Length | 5.0" plus top and bottom margin (5.24" min) |
| Maximum Roll Diameter | Up to 6.69" |
| Maximum Roll Weight | 27 lbs |
| Media Thickness | 0.07 mm to 0.80 mm (roll and sheet media) |
| Roll Paper Remaining | Printable barcode tracking system – The amount of remaining media can be controlled and monitored from the front panel |
| Top/Bottom Margins (mm) | Normal: 20/15 (Premium Luster Photo Paper); Option: Top 3, 15, 20, 45/Bottom 3, 15 |
| Left/Right Margins | 3 mm each side; 0.24" total; or 0" at BorderFree® width |
| Integrated Take-Up Reel | Auto forward and backward; light- based media sensor with inner and outer winding options |
| BorderFree Print Widths | 10", 11.8", 13", 16", 17", 20", 20.3", 23.4", 24", 28.7", 33.1", 36", 40.6", 44" |
| Single Sheet, Front or Rear Loading | up to 44" wide |
| Minimum Sheet Width | 8" |
| Maximum Sheet Width | 44" |
| Media Thickness | 0.07 mm to 0.8 mm |
| Posterboard | 0.8 mm to 1.5 mm |
| Top/Bottom Margins | 3 mm/15 mm |
| Top/Bottom Margins with Centering On | 15 mm/15 mm |
| Left/Right Margins | 3 mm each side; 6 mm or 0.24" total; or 0" at BorderFree sizes |
| Line Accuracy | ±0.1% of specified length (±0.26 mm min.) |
| Minimum Sheet Size (Single Sheet) | 8.5" x 11" |
| Maximum Printable Length | 298' |
| Minimum Paper Width | Roll: 10"/Sheet: 8" |
| Articulating LCD Display | 4.3" Touchscreen |
| Printer Interfaces | SuperSpeed USB 3.0, 100BASE-TX /1000BASE-T/IEEE 802.11 b/g/n/ac, USB memory stick, 960 GB SSD Optional |
| Operating Systems | Mac® OS X® 10.9.5 or later, macOS® 11 or later Windows® 10, Windows 8.1, Windows 8, Windows 7, Windows Vista® , Windows XP® (32-bit/64-bit), Windows Server® 2019/2016/2012 R2/2012/2008 R2/2008/2003 R2/2003 SP2 or later |
| Dimensions (W x D x H) | 73" X 20" X 39" |
| Weight | 347.2 lbs |
| Acoustic Noise Level | Operating: 49.6 dB(A) according to ISO 7779 |
| Temperature | Operating: 50 ˚ to 95 ˚F (10 ˚ to 35 ˚C) Operating (Recommended): 65 ˚ to 75 ˚F (18 ˚ to 24 ˚C) Storage: -4 ˚ to 104 ˚F (-20 ˚ to 40 ˚C) |
| Relative Humidity | Operating: 20% – 80% (no condensation) Operating (Recommended): 45% – 60% (no condensation) Storage: 5% – 85% (no condensation) |
| Safety Standards | USA and Canada (NRTL Certified, CSA/UL 62368-1). Compliant with FCC Class B Requirements. |
| Electrical Requirements | Voltage: AC 110 V – 240 V Frequency: 50 Hz – 60 Hz Current: 3.4 A – 1.6 A |
| Power Consumption | Printing: Approx. 70 W Ready: Approx. 32 W Sleep: 2 W (1000Base-T Ethernet in Standby) Power Off (Stand By): 0.3 W |
- Brand: Epson
- Availability: In Stock
USD 3,400.00
