| MODEL NUMBER | SC-F9430H |
| Printer Width | 64” |
| Printhead | Dual PrecisionCore™ TFP® Printhead |
| Nozzle Configuration | 360 nozzles x 5 channels x 2 head |
| Maximum Resolution | 720×1,440 dpi |
| Resolusi & Kecepatan Cetak | Production (2 pass): Up to 62 m²/jam (360 x 720 dpi) |
| Production (4 pass): Up to 32.1 m²/jam (720 x 720 dpi) |
| Production (6 pass): Up to 21.9 m²/jam (720 x 720 dpi) |
| Production (8 pass): Up to 15.8 m²/jam (720 x 720 dpi) |
| Ink Type | Epson UltraChrome™ DS6 dye-sublimation ink |
| Colours | 6 colours – Cyan, Magenta, Yellow, High Density Black, Fluorescent Yellow, Fluorescent Pink |
| Ink Capacity | Cyan, Magenta, Yellow, High Density Black: 1,100 ml ink pouch Fluorescent Yellow, Fluorescent Pink: 1,000 ml ink pouch |
| Paper Handling | Rear roll feed (2” / 3” core with max 250 mm diameter and up to 45 kg); Auto take-up reel |
| Printable Area | Max printing width: 1,615.6 mm; Side Margin: 5 mm both sides, 10 mm with media holding guides |
| Media Width | 300.0 mm (11.8”) – 1625.6 mm (64”) |
| Media Thickness | Up to 1 mm |
| Control Panel | 2.7” Colour LCD |
| Printer Interfaces | Hi-Speed USB, 100BASE-TX /1000BASE-T |
| Printer Languages | Standard: ESC/P raster |
| Memory | 512 MB main + 128 MB network |
| Software | Bundled in CD (Windows Only): CD installer, Epson communication Driver, Epson manual Launcher, Operators Guide, General Information, Epson Control Dashboard, EpsonNet Setup, EpsonNet Config, EpsonNet Print, Software Updater, DVD(Epson Edge Print bundle SKU only) Epson Edge Print, Epson Control Dashboard, Epson Communication Driver Web Delivery (Mac and Windows): Windows and Mac: CD installer, Epson communication Driver, Epson manual Launcher, Operators Guide, General Information, Epson Control Dashboard, EpsonNet Setup, EpsonNet Config, EpsonNet Print, Software Updater, LFP Accounting Tool |
| Power Requirements | AC 100-120 V AC 200-240 V 50/60 Hz |
| Power Consumption | Operating: Approx. 600 W; Ready: Approx. 380 W; Sleep: Approx. 14 W; Power Off: Approx. 1.0 W |
| Recommended Operating Temperature & Humidity | Operating: 15 °C to 35 °C, Storage: -20 °C to 60 °C |
| Dimensions | 2,620 x 934 x 1,332 mm (WxDxH) |
| Weight | 290 kg (without ink) |
| Bundled Items | Substrate Support System and Ink Supply System (C12C934971), Initial Ink Pack Set 10 (C12C934741) x2, Initial Ink Pack Set 11 (C12C934991) x1 |
| Warranty | 1 year |
